Cypress Series

Chiller Cabinets

Wide Spectrum of Applications!

Consists of general use Chiller Cabinets for Food preservation, with longevity and heavy duty construction as main characteristics. The Cabinets are Energy Efficiency Class certified according to the current European Legislation.

Operating temperatures range from -2°C to +8°C, while their evaporator is protected against corrosive agents present inside the foodstorage area.

In 2019, four new models are added, that work with the environment friendly, naturally occurring, refrigerant R290 for more than 20% energy savings!

Clear
Categories: , SKU: N/A Tag:

Features

  • Energy Classification according to the European Standards EU 2015/1094 & 2015/1095
  • AISI 304 18/8-10 stainless steel construction
  • Available in depth sizings of 868mm & 768mm
  • Anti-corrosive protection on the evaporators
  • Injected polyurethane foam insulation, 60mm in thickness
  • Ergonomically designed interchangeable 70 mm thick doors with lock, equipped with auto-return mechanism at an angle of 45° or less
  • Hygienically designed rounded corners, clip-on shelving system, clip-on magnetic gaskets easy to clean
  • Automatic condensates evaporation
  • Forced air circulation technology
  • Embedded thermostat for easy operation and cleaning
  • Two-door cabinets include bridging shelves for increased storage space
  • R404 refrigerant or the environmental friendly refrigerant R290 for more than 20% energy savings!
  • Operating temperatures range -2οC to +8οC for a wider range of applications!

Specs Table

Model Dimensions (mm) Capacity (Lt.) Doors No Shelves No Operating Temperature °C Refrigerant Energy Class Climate Class Compressor
CAP172 720x868x2100 654 1 3 -2 / +8 R290 D 5 Embraco
CAS172 720x868x2100 654 1 3 -2 / +8 R134a F 5 Embraco
CAP172/SL 720x768x2100 560 1 3 -2 / +8 R290 D 5 Embraco
CAS172/SL 720x768x2100 560 1 3 -2 / +8 R134a F 5 Embraco
CEP2144 1440x868x2100 1432 2 6 -2 / +8 R290 E 5 Embraco
CES2144 1440x868x2100 1432 2 6 -2 / +8 R134a F 5 Embraco
CEP2144/SL 1440x768x2100 1227 2 6 -2 / +8 R290 E 5 Embraco
CES2144/SL 1440x768x2100 1227 2 6 -2 / +8 R134a F 5 Embraco
